1.Please carefully confirm the model purchased. There are many options in this link. The SKU image is also very clear. “ONLY” means only this part (no other parts). We don’t want to cause misunderstanding to every friend
Wireless switch does not have WIFI function, only RF433MHZ function The controller has WIFI+RF433MHZ+APP+ voice function
1.433MHZ RF function + WIFI function 2 in 1, smarter and more user-friendly 2. Pass CE, FCC, ROHS certification: 100% inspection before transportation to ensure product safety 3. Highly sensitive design, Drawer box design, Luminous fluorescent strip, Drop resistance design, Large panel, etc. 4.Professional after-sales team: Shoot a large number of videos to handle various anomalies and quickly solve customer problems
Wireless control mode
433MHZ RF +Voice control + APP control
Why does the WIFI controller need to increase the RF function?
1. It is more convenient to use at night and can be placed at the bedside. easy to use 2. The wireless switch has a fluorescent function and it is easy to find the wireless switch.
The disadvantage of APP control + voice control at night
APP control: The night is too dark, it is difficult to find a mobile phone. And the operation is cumbersome Voice control: disturb the child to sleep, sounds in the middle of the night will scare the crying child
APP Remote Control
As long as the phone has a WIFI signal, Control the appliance at any time through the APP
You can set a countdown for humidifiers, microwaves, coffee machines and more. The device will stop automatically. Don’t worry about the device working all the time
Set the time to turn on the light. Set time to cook rice…
3 Kinds Of Restart State
1.Turn off the lights, turn on the lights, and operate before the memory 2.No need to worry about the status of the lights when going out
Works perfectly with Amazon Alexa,Google Home,
Family Sharing Control Fun
main account has the exclusive permissions,one click to share the permissions with the whole family.let the family enjoy the fun of smart life!
More convenient remote control fun
When you wake up at night, the wireless switch is more convenient.and will not affect the rest of the baby and family.
WIFI Remote Control
No distance limit, as long as there is WIFI
433MHZ RF Remote Control
Wireless distance 50M (in open area)
How to match 433MHZ wireless switch
1 Press the learning key twice quickly ,and see the indicator flashing 2.Press the wireless switch once ,and the signal is successfully paired
How to clear the 433MHZ RF signal
Press the learning key 8 times quickly ,and see the indicator flashing,Signal clearing succeeded
How to add device to mobile app
1.Scan the QR-code of the manual or Search ‘ Smart Life ’ to download and install the device’s APP 2.After the wiring is completed, turn on the power and operate according to the status of the smart switch indicator: 3.If the red light of the smart switch flashes continuously at this time, it indicates that the smart switch has entered the state of waiting for connection to WiFi; then open the APP and follow the instructions to connect to WiFi. 4. If the indicator light of the smart switch is not flashing red light, please press the button of the smart switch and keep it for more than 5 seconds until the red light flashes continuously, then open the APP and connect to the WiFi according to the manual.
1.Working voltage: AC90-250V 60HZ/50HZ 2.WIFI: IEEE 802.11 b/g/n 3.RF Working frequency: 433.92MHZ 4. Maximum current: <10A 5. Size: 83 * 42.3* 25 (mm) 6.Enclosure Material: Fire-retardant ABS
Wireless switch parameters:
1, working voltage: DC 3V 2, working frequency: 433.92MHZ 3. Transmitting power: <10mW 4. Remote control distance: <50 meters (indoor distance) 5, size: 86 * 86 * (mm) 6.Cr2032 battery, standard battery, (Does not contain battery)About 1 year can be used 7.2 kinds of fixing methods: screw + double-sided adhesive
HD tempered glass
1.Glass reinforced process, not afraid of sharp objects scratching 2.The surface is smooth and it is very clean when wiped gently
Drawer box design
Cr2032 Battery , easy to replace the battery The service life is about 12 months. Life and frequency of use are related. Time may be longer (Does not contain battery)
Luminous fluorescent strip
Middle of the night, do not worry about finding the switch
Drop resistance design
Protective housing,four-corner arc transition, buffer protection
1.It is more convenient because it is bigger 2.Small remote control is easy to lose
Mobile phone shooting
Passed CE, fcc ,RoHs certification,
How to solve the problem (if the product has a problem)
1. First check if the battery model is correct (Cr2032 battery)? Is the battery charged? 2.please provide an email and we will send you video. You can try the following steps. First you can clear the signal . Then re-pair the signal 3. If these questions still don’t solve the problem, please send the video to our email address (firstname.lastname@example.org). We check if your method is correct. If the product is really defective, we will re-deliver the wireless switch or controller to you.
1.Why is the device unstable on the app?
1. Each router having the connection limited, but more and more smart device working on family 2. A lots family still using very old version routerseven more than 3years ago version. In order to have excellent experience, the suggestion is : 1. re-set the router connection limited 2. change a new update version router 3. please note these switch only work on 2.4G wi-fi network, not 5G.
2. Why the APP can’t find the device in pairing status?
That’s because of your phone’s cache. Please close the WLAN of your phone then open it after a minute. At the same time,please power off the device if you can, then power up to try again.
First suggest to view the instructions. If you still have problems, please contact us. We send videos to help you
1. Professional electrician should operate this product. When powering on, do not touch the antenna. Install this product without opening the protective cover 2.This controller will not be available if a wall switch with RF function is installed at home. Otherwise the function will be affected. Just need to buy a separate wireless switch 3. Do not operate with power. Turn off the power supply and operate it. If the test is confirmed to be correct, use it under the guidance of a professional electrician. 4. When the voltage of the remote control is insufficient, please change the battery in time (the remote control distance becomes closer when the remote control battery voltage is insufficient). 5. When using wireless electronic products, care should be taken to avoid metal masks, large electronic devices, electromagnetic fields, etc., which have strong interference sources, to avoid remote control and short receiving distance or to work normally. 6. Do not use this electronic product abnormally. Abnormal use will reduce product performance and longevity. In severe cases, damage to the product will also pose a safety hazard.
